Xinxiang Tongxin Manufacture Chain Plate Conveyor 20 Years Experience Soil
Introduction
Chain scraper conveyor is powder or small granular conveying equipment, which consists of head section with driving device, connect section, tail section, tension device, as well as scraper and chains.
By means of moving chains, it can continuously transport the materials in closed rectangular casing horizontally or at a slight incline.
Specifications
| Chain Plate Material | Carbon steel, stainless steel, thermoplastic chain. According to the needs of your conveyed product, you can select different width and shape of the chain plate to complete the plane transportation, the plane turning, elevating, falling requirements. |
| Chain Plate Specification | Straight transmission chain plate width: 63.5, 82.5, 101.6, 114.3, 152.4, 190.5, 254, 304.8mm. |
| Turning Chain Plate Width | 82.5, 114.3, 152.4, 190.5, 304.8mm. |
Features
1. Reasonable structure;
2. Large Conveying capacity;
3. Small Power consumption;
4. Less wear;
5. Reliable work;
6. Ideal waste paper transportation equipment.
Application
Widely used in food, canned food, medicines, beverages, cosmetics and cleaning products, paper products, condiments, dairy and tobacco and other automatic transmission, distribution, and transportation connections after-packaging.
Working Principle
There are internal frictional forces and internal pressures between the particles of the bulk material.
They are subjected to the pulling force in the same direction as the movement caused by the movement of the conveyor chain in the slot of the chain conveyor, so that the internal friction and internal pressure between the bulk materials Increase, when the internal friction is greater than the friction between the material and the groove wall, the material moves forward under the conveyance chain.
When the ratio of the height of the layer to the width of the groove meets certain conditions, the flow is stable. The material rate is approximately equal to the chain speed.
Technical Parameters
| Chain Pitch | 25.4mm-203.2mm |
| Plate Chain Conveyor Width | 200mm-800mm |
| Conveyor Speed | 0.4m-15m/min |
| Maximum Weight Delivery Items | 800kg/m² |
| Metal Plate Chain Working Environment Temperature | -20°C-+120°C |
Our Advantage
The product of Tongxin company can be sent to the Quality and Technical Supervision Bureau for mesh detection, if not in line with the national standards for you free return and replacement. The follow picture is our quality inspection report.
Our Service
1. We Provide video installation instructions;
2. We offer 24-hour online consulting service;
3. 20 years production experience to ensure quality;
4. We have thorough data to ensure the quality;
5. We provide detailed instruction an product information;
6. We provide 12 months quality warranty.
If you want to get more information of product, please contact us!
